CPINFO20 Web Development

Final Hackathon

Steganography Stéganographie

the practice of concealing a file, message, image, or video within another file, message, image, or video - wikipedia

You will need these 2 packages:

• lsb
• jimp

There are 5 images with data encoded in them.

The data has the following format:

{
  index: 0,
  message: 'a secret message...',
}

Using these images:

• a.png
• b.png
• c.png
• d.png
• e.png

Use the following decode() function to decode the embedded data.

const jimp = require('jimp');
const lsb = require('lsb');

async function decode(inputImage) {
  const image = await jimp.read(inputImage);
  const json = lsb.decode(image.bitmap.data, rgb);
  return JSON.parse(json);
}

function rgb(n) {
  return n + Math.floor(n / 3);
}

/////////////////////////////////////////
// EXAMPLE - This can be deleted
//
async function example() {
  const secret = await decode('./a.png');
  console.log(secret);
}

example()
//////////////////////////////////////////

Deploy a page that dynamically:

1. orders the images based on the value of the index field encoded in the image. All 5 images should be displayed in the correct order.
2. displays the secret message by concatenating the message segments in the order determined from their index. The entire message should be displayed.
3. Serve a webpage that includes steps 1 and 2. You can use express (optionally with pug) or react
4. Bonus Deploy your site to the cloud using firebase or next.js

To get started (with express):

mkdir hackathon
cd hackathon
npm init
npm install --save express lsb jimp
